ULTRA HIGH DEFINITION (UHD) RESOLUTION AT A FRACTION OF THE COST
You get all the benefits of a UHD display at a fraction of the cost! Our PWD110R digital display non-touch series have true-to-life colour reproduction and detail with superb clarity while saving space with a slim design.
ADSDS TECHNOLOGY
PURPLEWAVE we seek to bring this happiness to a higher level. As one of the world's leading Ultra Hard screen technologies, the unique ADSDS (Advanced Super Dimension Switch) technology owned by PURPLEWAVE provides higher transmittance, brightness, and contrast ratio, as well as a visual angle of about 180° to present a vivid image effect. Mean while, the ADSDS panel is featured by low power consumption and environmental friendliness and can be used as the screen of smart phones, tablet PCs, laptops, displays, and TVs.
Specifications
| Parameter | PWD110R | Parameter | PWD110R |
|---|---|---|---|
| Screen Size | 110 inch | LCD Tech | ADSDS |
| Native Resolution | 3840x2160 | Aspect Ratio | 16:09 |
| Refresh Rate | 120Hz | Brightness | 500 cd/m |
| Contrast | 1200:01:00 | View Angle | 178°(H) / 178°(V) |
| Color Depth | 1.07G (8Bit+Hi-FRC) | Color Gamut | 95% |
| Response Time (G to G) | 8ms | Surface Treatment | Haze 1% |
| Installation Orientation | Lanscape & Portrait | Life Time (Light Source) | 50,000 Hrs |
| Input | HDMI x 4 (1.4 × 2, 2.0 × 2), DP × 2 (1.2 × 2) | Output | DP x 1 (1.2) |
| External Control | Rs232 x 1 (RJ45) | Networks | LAN x 2 |
| Built-In Speaker | 2 × 10W (8Ω) | Bezel | 17 mm (Even Bezel) |
| Body Dimension (Set Only) | 2474 (W) x 1408 (H) x 90 (D) mm | Set Weight (Set Only) | 80 Kg |
| Package Dimension | 2730 (W) x 1737 (H) x 496 (D) mm | Package Weight | 110 Kg |
| VESA Mounting Interface | 1500 x 800, M16 | Power Supply | ≤ 600 W |
| Power Switch | Built-In | Power Consumption (Typ.) | ≤ 1000 W |
| Power Consumption (Standby) | ≤ 0.5 W | Operation Temperature | 0°C~40°C |
| Operation Humidity | 10%~80% RH |
