Ready to use Active LED Panel with Superior Quality
Creativity with simplicity, Purple Wave Infocom Ltd is a dedicated category brand specially established by Purple Wave Infocom Ltd for the global LED display channel market based on the development concept of “Ready-to-use LED, to fit your demands”. Purple Wave Infocom Ltd have excellent performance, simple design, flexible splicing, convenient maintenance and other characteristics.
Specifications
| Parameter | P3 | Parameter | P3 |
|---|---|---|---|
| LED Type | Black SMD2121 | Pixel Pitch (mm) | 3.07 |
| Panel Dimensions (W*H*D) (mm) | 640x480x60 | Panel Resolution | 208x156 |
| Panel Weight (kg) | 7.8 | Panel Material | Die Casting Aluminum |
| Module Size (W*H) | 320x160 | Brightness (nit) | 700 |
| Refresh Rate (Hz) | 1920~3840 | Grayscale (bit) | 13~14 |
| Contrast Ratio | 4000:01:00 | Color Temperature (K) | 6500 |
| Viewing Angle (H/V) (°) | 140/140 | Drive Mode | 1/26 |
| AC Operating Voltage (V) | 200~240 | Power Consumption (Max./Avg.) (W/m²) | 540/180 |
| Storage Temperature (°C) | -40~60 | Operating Temperature (°C) | -10~40 |
| Storage Humidity (RH) | 10%~85% | Operating Humidity (RH) | 10%~80% |
| IP Rating (Front/Rear) | IP40/IP21 | LED Lifetime (H) | 100000 |
| Module Maintenance | Fully front/rear | PSU & Other Maintenance | Fully front/rear |
| Panel Installation Type | Stacking/Wall-mounting/Hanging |
