PURPLEWAVE Interactive Touch Displays are large touchscreen displays designed for use in educational, corporate, and professional settings. They combine the features of a high-resolution display with the interactive capabilities of a touchscreen, enabling users to interact directly with the content.
Specifications
| Display | PWD43TRX | Display | PWD43TRX |
|---|---|---|---|
| Screen Size | 43" | Resolution | 1920x1080 |
| Bonding Technology | Zero Bonding | Display Orientation | Landscape |
| Screen Type | TFT LCD (Direct-LED Backlight) | Blue Light Reduction | Yes |
| Pixel Pitch | 0.49(W) x 0.49 (H) | Aspect Ratio | 16:9 |
| Display Area | 983.9x582.3x62.8 | LCD Viewing Angle | 178° H/V |
| Response | 8ms | Refresh Rate | 60Hz |
| LED Lifespan | 60,000* Hours | Contrast Ratio | 3000:1 Dynamic, 1200:1 Static |
| Brightness | 350 | Glass Hardness | 9H (Pencil), 7 (Mohs) |
| Glass Type | Heat tempered, Anti-Glare | Touch Type | Infrared touch, 20 points touch (Android), 40 points (Windows) |
| Response Time | 8ms | Touch Object | All Opaque object, such as Finger, pen etc. |
| Operating System | Android 13 | RAM | 4GB |
| Internal Storage | 32GB | CPU | Amlogic T982, Quad Core ARM Cortex-A55 CPU, 1.9 GHz |
| GPU | Mali-G52 MP2 (2EE) | UI Language | English, Hindi, Gujrati, Kannada, Telgu |
| Video / Picture Decoding |
Independent JPEG and H.264 encoder with configurable H.264 video encoding up to 1080P@30fps with low latency |
||
| Dual Speakers | 2 x 15W | LAN in(RJ45) | 10/100Mbps |
| Wake-on-LAN | Yes | Wi-Fi | IEEE802.11A/b/g/n/ac, 2.4G, 5G |
| Bluetooth | 5.0 | Power Requirements | 100V ~ 240V AC, 50/60HZ |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) | Storage Temperature | -15°C to 55°C (-5°F to 131°F) |
